Hexanium ACIF Stand-Alone 3D Printed Ti ACDF Spacer

SPECS

Product Category: Spinal Implants

By Product Type: Interbody Device

Cage Type: Interbody Cage/Cervical

Expansion: Static

Cage Approach: Anterior

Configuration: 0-Profile (Integrated screws)

Cage Material: 3D Printed Titanium

By Location/Approach: Anterior Cervical

By Procedure Type: ACDF

By System Type: Degenerative , MIS/Perc

DESCRIPTION

The Hexanium ACIF Cage by SpineVision is a 3D printed standalone cervical interbody fusion system made of titanium with integrated zero-profile design, one-step locking mechanism, honeycomb structure, high porosity, and osteoconductive properties for enhanced bone fusion.

Features:


  • Material:
    •  3D printed titanium
    • Rough titanium surface for enhanced tissue contact
    • High porosity honeycomb structure
    • Maximized porosity for enhanced surface areas
  • Design Features:
    •  Zero profile cage
    • Integrated one-step locking mechanism
    • Honeycomb-like structure with multiple windows for bone graft distribution
    • Osteoconductive design to promote fusion
  • Footprint options:
    • Small: 15x12mm
    • Medium: 17x14mm
    • Large: 19x15mm
  •  Lordosis options:
    • 6° lordosis (available for both shapes)
  • Height options:
    •  5-12mm in 1mm increments (8 total heights)
  • Shape options:
    • Wedge
    • Convex
  •  Screw options:
    •  Self-drilling screws
    • 3.5mm or 3.8mm diameter
    • Fixed angles: 38° cranial/caudal, 10° median/lateral plane
  • Regulatory: CE marking: Yes FDA clearance: Yes
  • Instrumentation:
    •  Specific guides for screw positioning
    • Smart distractor compressor system
    • Streamlined and ergonomic design
