MaxAn Anterior Cervical Plate

SPECS

Product Category: Spinal Implants

By Product Type: Plates

Plate Location: Cervical

Plate Approach: Anterior Plate

Plate Configuration: Stand-Alone Plate

Plate Dynamics: Static Plate

By Location/Approach: Anterior Cervical

By Procedure Type: ACDF

By System Type: Degenerative

By Material: Titanium (Solid)

DESCRIPTION

The MaxAn Anterior Cervical Plating System from Highridge medical is a single to 3 level plate designed for the supplemental fixation for the ACDF procedure. Features of this plate is the maximum angulation of the screws that allow for plate to encroach less on the adjacent levels to prevent breakdown.

Features:

  • Titanium construction
  • Up to 30 degree cranial/caudal angulation
  • Locking ring to prevent screw backing out
  • Plate thickness: 2.51mm
  • 1-3 level plate options
  • Plate Height: 8-130mm
    • 1 level: 8-20 in 1mm increments
    • 2 level: 20-40mm in 2mm increments
    • 3 level: 36-66mm in 3mm increments
